The FIT14 is an aftermarket, USA-made frame, inspired by the increasingly younger shredders on the scene. The first of its kind, the FIT14 is the only aftermarket 14” wheel BMX frame in production, and when paired with S&M’s corresponding fork and smaller bars, you can rest assured your little dudes and dudettes are mounted on the industry’s best… on an ergonomically-built BMX designed to let them ride their best!
Specifications:
- Butted Supertherm Top Tube
- Straight Gauge Supertherm Down Tube
- Double Gussets
- Slightly Tapered Seat Stays
- Slightly tapered Single Bend Chain Stays
- 2.4″ Tire Clearance (even when slammed)
- Double Butted Seat Tube
- Longer Drop Out Slots
- Welded on Chain Stay Brake Mounts
- Thru the Seat Tube Cable Routing
- Double Down Tube Cable Guides
- Engraved Key Logo Head Tube
- American Made
- Sizes : 21″, 21.125″, 21.25″, 21.5″
- Rear end length : 13.8″-14.5″
- Head tube angle : 74.5°
- Seat tube angle : 71°
- BB height : 11.35″
- Standover : 9.15″
- Head tube : Integrated
- Bottom Bracket : Mid
- Dropouts : 14mm, 3/16″ Thick, 4Q Baked
- Brake mounts : Chainstay Welded 990s
- Seat clamp : Traditional Slot
- Seat post size : 25.4mm
- Weight : 21” – 5.18 lb (2.35 kg) | 21.125” – 5.235 lb (2.37 kg) | 21.25” – 5.27 lb (2.39 kg) | 21.5” – 5.3 lb (2.4 kg)
