Designed by Ty Morrow and constructed with 4130 chromoly throughout. Features include heat-treated Mid bottom bracket shell and integrated head tube, a double-butted top tube with external gusset, oval double-butted down tube with external gusset, externally butted seat tube with integrated clamp, tapered seatstays and heat-treated 6mm thick dropouts with integrated tensioners.
*Due to the nature of semi-transparent paint finishes the character of the raw tubing will be visible and may contain vein-like abnormalities making each frame & unique.
Specifications:
- Top Tube Length: 20.75"
- Head Tube: 75.5°
- Seat Tube: 71°
- Stand Over: 9"
- BB Height: 11.625"
- Rear Triangle: 12.9"
- Material: Chromoly
- Headset Style: Integrated
- Bottom Bracket Style: Mid
- Frame Brake Style: Brakeless
- Post Diameter: 25.4mm
- Wheel Size: 20"
